TS-60
Introduction
TS-60 is built-in Non contact Infrared thermometer and smoke sensor.
The most of existing temperature and smoke sensors in markets can detect fire after the heat reach to temperature and smoke detector.
However, TS-60 detects the fire by increased infrared amount and low concentrated smoke in early stage of the fire and enables to prevent the fire in advance.
Specification
Detection Principle | Ionizations Smoke Chamber |
Detection Method | Diffusion |
Response time | Within 3 sec |
Relay Output | Relay A (DC30V 1A) |
Input power | DC 22V~26V |
Currency consumption | 50㎃. Maximum |
Operation temperature/humidity | -20℃~ 60℃ / 0 ~ 95% RH (Non-Condensing) |
Process | Digital Process |
Temperature setting in factoy | 50℃ |
Smoke density | 1% |
